1.27mm pitch IDC Flat Ribbon Cable Assembly

Ribbon Cable Assemblies0397

These 1.27mm(.050") pitch IDC terminals, sockets, and connectors feature our high-reliability improved contacts and a variety of rugged options.

Key Features

  • High-performance Improved contacts
  • Choice of socket and plug terminations
  • Exceptionally low profile .200" (5.08 mm)
  • Variety of options including strain relief
  • Mating shrouded & ejector terminal strips
  • Wide variety of standard wiring configurations

Description

RichCables High-density 1.27mm(.050") IDC flat ribbon cables, ideal for compact, organized data and signal transmission. Featuring 28 AWG tinned copper conductors, durable PVC insulation, and compatibility with IDC connectors, these cables are perfect for computer peripherals, automotive electronics, and industrial equipment. Available in multiple conductor options, this flexible, color-coded cable ensures efficient and interference-free connections for space-constrained applications.

Specification

Item Specification
Pitch 1.27mm (0.05")
Conductor Size (AWG) Typically 28 AWG
Conductor Material Tinned copper for corrosion resistance and conductivity
Number of Conductors Available in multiple configurations (e.g., 8, 10, 16)
Insulation Material Typically PVC (Polyvinyl Chloride) for durability
Temperature Range -20°C to +105°C
Voltage Rating Typically 300V, depending on insulation and design
Current Rating Approximately 1A per conductor at 28 AWG
Flame Retardant Meets UL standards (e.g., UL 2651) for flame resistance
Color Usually gray or color-coded
Insulation Thickness Around 0.9mm (may vary based on conductor count)
Flexibility Designed for limited flexibility, bendable for routing
Operating Humidity Up to 85% non-condensing
Compatibility Designed for IDC connectors, headers, and sockets

Applications

  • Computers and Peripherals: Connections between internal components, such as hard drives, floppy drives, and CD-ROMs.
  • Industrial Equipment: Used in control panels, data communication equipment, and instrumentation.
  • Automotive Electronics: For internal connections in dashboards and electronic systems.
  • Medical Devices: Compact design is suited for connections in medical diagnostic equipment.
  • Telecommunication: Interconnections in telecom switches and network devices.
